Description
Experience precision with Bedook Inductive Proximity Sensor Cube 2/4/5mm DC 3 Wire, featuring advanced anti-interference in sensor technology. Precision made accessible.
Inductive Switch Product Features:
Introducing the Bedook Inductive Proximity Sensor Cube, a leap forward in precision sensing technology:
- Variety in Size: Choose from dimensions ranging between 8×7.4x20mm to 15×8.2×31.6mm.
- Multiple Types Available: NO/NC outputs, alongside PNP and NPN types, cater to various application needs.
- Enhanced Anti-Interference Design: The DC three-wire design not only simplifies installation but significantly boosts the sensor’s immunity to interference, assuring highly accurate repeatability.
- Unmatched Precision: Achieve less than 1.0% repeatability for reliable and consistent operation.
- Durability and Resilience: Constructed from robust PBT/ABS materials, guaranteeing sensor longevity.
- Designed for Harsh Conditions: With IP67 ingress rating and a temperature range from -25 to 70℃, it’s perfectly suited for extreme environments.
Inductive Switch Technical Parameters:
Switching Frequency: 500Hz(2.5mm)/2000Hz(4/5mm)
| Appearance |  |
 |
 |
 |
 |
|
| Model | NPN NO | BN-Q882.5 N-P11P2 | BN-Q882.5N-P11P2-T | BB-Q1002N-P11P2 | BB-Q1204N-P11P2 | BN-Q1505N-P11P2 |
| NPN NC | BN-Q882.5N-P21P2 | BN-Q882.5N-P21P2-T | BB-Q1002N-P21P2 | BB-Q1204N-P21P2 | BN-Q1505N-P21P2 | |
| PNP NO | BN-Q882.5P-P11P2 | BN-Q882.5P-P11P2-T | BB-Q1002P-P11P2 | BB-Q1204P-P11P2 | BN-Q1505P-P11P2 | |
| PNP NC | BN-Q882.5P-P21P2 | BN-Q882.5P-P21P2-T | BB-Q1002P-P21P2 | BB-Q1204P-P21P2 | BN-Q1505P-P21P2 | |
| Appearance Structure | 8*7.4*20mm | 8*8*23mm | 10*6*27mm | 12*7.2*31.2mm | 15*8.2*31.6mm | |
| Sensing Distance | 2.5mm(Non-flush mounting） | 2.5mm(Non-flush mounting） | 2mm(flush mounting） | 4mm(flush mounting） | 5mm(Non-flush mounting） | |
| Switching Frequency | 500Hz | 500Hz | 500Hz | 2000Hz | 2000Hz | |
| Operating voltage | 10…30VDC(±10%) | 10…30VDC(±10%) | 10…30VDC(±10%) | 10…30VDC(±10%) | 10…30VDC(±10%) | |
| Voltage drop | ≤2.0V | ≤2.0V | ≤2.0V | ≤2.0V | ≤2.0V | |
| Load current | 100mA | 100mA | 100mA | 200mA | 200mA | |
| Leakge current | ≤0.01mA | |||||
| No load current | ≤10mA(24V) | |||||
| Hysteresis | ＜15%(Sr) | |||||
| Repeatability | ＜1.0%(Sr) | |||||
| Switch protection | Short Circuit Protection, Polarity reversal Protection, Power-On Protection | |||||
| Indication LED | With (Action: LED Indicator Lights Up) | |||||
| Ambient temperature | -25…70℃ | |||||
| Ingress protection | IP67 | |||||
| Housing Material | PBT/ABS | |||||
| Face material | PBT/ABS | |||||
| Connectors | 2m PVC Cable, 3*0.18mm² | |||||
| Accessories | No | |||||
Inductive Switch Size Chart:
Bedook Inductive Proximity Sensor Cube 2-4-5mm DC 3 Wire-Size-01
Rely on Bedook Inductive Proximity Sensor Cube 2/4/5mm DC 3 Wire for high-accuracy results even in the most demanding environments. Transform your project today.
At Bedook, we pride ourselves as leaders in crafting state-of-the-art sensor solutions.
Our commitment to competitive pricing, customizable products, and unparalleled quality assures that your projects are elevated with Bedook’s innovations.
Contact us for a quotation and make the most out of our professional-grade proximity sensors.
