Bedook Label Slot Ultrasonic Sensor Switch Output – UG50
Bedook Label Slot Ultrasonic Sensor Switch Output – UG50 features a 3mm slot, operates at 10-30V DC with 1500Hz frequency, and offers fast 250μs response time. With NPN/PNP switching output and IP65-rated aluminum housing, it ensures reliable and precise label detection in demanding environments.
Description
Bedook Label Slot Ultrasonic Sensor Switch Output – UG50, is designed for high-precision detection of label presence, position, and gaps. Its robust build and advanced ultrasonic technology make it ideal for various labeling applications, ensuring accuracy and reliability.
Product Features:
Bedook UG50 Label Slot Ultrasonic Sensor provides exceptional performance in detecting and positioning labels with its advanced ultrasonic technology. Suitable for diverse labeling processes, it offers a reliable and efficient solution for your production needs.
- High-Precision Detection: Detects label presence, position, and gaps with minimal error, ensuring consistent accuracy in labeling operations.
- Versatile Output Options: Offers both NPN and PNP switching output, accommodating various system requirements with easy integration.
- Fast Response Time: With a response time of just 250μs, it supports high-speed operations, making it suitable for fast-paced production lines.
- Robust Construction: Aluminum housing and IP65 ingress protection provide durability and resistance to harsh environments.
- User-Friendly Setup: Features easy-to-use buttons for sensitivity adjustment and NO/NC switching, facilitating quick and flexible configuration.
- Global Certifications: Complies with CE, UKCA, and ROHS standards, ensuring global compatibility and high quality.
| Appearance | ||
| Model | NPN/PNP | UG50-L030F-A31S8 |
| Dimensions | 85.6*18.2*53mm | |
| Slot width | 3mm | |
| Slot longth | 69mm | |
| Operating voltage | 10…30V DC | |
| Ripple | <10% | |
| current consumption | ≤50mA | |
| Switching frequency | 1500Hz | |
| response time | 250us | |
| Switching output | NPN/PNP | |
| Switching output(Voltage) | PNP:high level=Uv≤2v/low level almost 0v | |
| NPN:high level=almost Uv/low level ≤2v | ||
| Switching type | no/nc switch | |
| Current output | 100mA | |
| Initialization time | 100ms | |
| connection method | M8 connector(4pins) | |
| Circuit protection | Yes | |
| Ingress protection | IP65 | |
| Housing Material | Aluminum | |
| Ambient temperature | +5…+55℃ | |
| Storage temperature | -20…+70℃ | |
| Shock load | EN 60068-2-27 | |
| Electromagnetic compatibility | EN60947-5-2 | |
Size Chart:
UG50 Label Slot Sensor by Bedook, featuring robust aluminum housing and fast response time, is designed for precise label detection and reliable performance in industrial applications.
